| Mode | LC165F-1H | LC168F-2H | LC165F-3H | | Engine type | Single cylinder,4stroke, forced cooling ,OHV | | Displacement | 166cc | 196cc | 149cc | | Bore×Stroke | 68mm×50mm | 68mm×54mm | 65mm×45mm | | Net power | 3.0kW/3600rpm | 4.1kW/3600rpm | 3.2kW/3600rpm | | Net torque | 7.7N.m/3200rpm | 12.4N.m/2500rpm | 8.8N.m/2800rpm | | Idle speed | 1800±150r/min | 1450±150r/min | 1800±150r/min | | Compression ratio | 8.5∶1 | 8.5∶1 | 8.5∶1 | | PTO shaft rotation | Anti-clockwise(from PTO side) | | Transmission mode | Chain mode | | Noise | ≤75dB(A) | ≤70dB(A) | ≤75dB(A) | | Ignition system | Transistorized magneto ignition | | Starting system | Recoil start/Electic-start | | Carburetor | Butterfly | | Lubrication system | Splash | | Governor system | Centrifugal mass type | | Air cleaner | Semi-dry,dual element | | Oil capacity | 0.6L | 0.6L | 0.5L | | Fuel tank capcity | / | / | / | | Net weight | 14kg | 16kg | 15kg | | Dimension | 370×335×345 | 350×312×350 | 336×290×348 |
|
