·OHV design enhances combustion efficiency
·High power-to-displacement ratio
·Easy starting with an automatic decompression system and an easy-to-grip soft recoil starter handle
·High quality materials and purpose-built components which ensure reliable, long-term use
·Meets world's most stringent environmental legislation
·Low fuel and oil consumption
·Reduced vibration and noise levels
Engine type | Single cylinder, 4-Stroke(0HV), 1/2 geared-down |
Bore*stroke | 68x45mm | 68x54mm | 88x64mm | 90x66mm |
Displacement | 163ml | 196ml | 389ml | 420ml |
Compression ratio | 9.0:1 | 9.0:1 | 9.0:1 | 9.0:1 |
Net power | 3.6kw/1800rpm | 3.8kw/1800rpm | 7.8kw/1800rpm | 8.8kw/1800rpm |
Net torque | 18N.m / 1250rpm | 19N.m/1250rpm | 50N.m/1250rpm | 53N.m/1250rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition |
Starting system | Recoil / Electric starter |
Lubrication system | Forced splash |
Carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical |
Air cleaner | Dual elements(paperorfoam) |
Oil capacity | 0.55L | 0.55L | 1.1L | 1.1L |
fuel tank capacity | 3.6L | 3.6L | 6.5L | 6.5L |
Dimensions(L*W*H) | 390 x320 x345mm | 390x320x345mm | 456x415x440mm | 456x415x440mm |
Net weight | 18kg | 18kg | 35kg | 35.5kg |
Fuel consumption | M395g/kw・h | 《395g/kw・h | 74g/kw・h | 《374g/kw・h |
