| CUTTING | | Max Log Capacity | 36″ Diameter | | Distance Between Guide | 31″ | | Max Thickness of Cut | 11″ | | Standard Track Length | 14′ / 2 – 7′ Sections | | Log Dogs | 2 Cam Style Dogs & Square Posts | | Max Log Length (with standard track) | 10′ | | Blade | 167 X 1.25 X .042″ | | Blade Lubrication | 5 Gallon | | Track Sweeps | No | | POWER | | Engine / Motor | 16hp Gas – Electric Start | | Clutch Engagement | Centrifugal | | CONSTRUCTION | | Frame | Modified 4 Post | | Bandwheels | 19″ | | Guide System | Dual Shoe Guides, 1 Adjustable | | Lift System | Manual Cable | | Measuring | Dual Scale 1″and 4,5,6,8 Quarter | | Main Bearings | 1.5″ | | WARRANTY | | 3-Year Limited Warranty | Residential Use | | 6-Year Warranty | Main Shafts and Bearings | | Accessories | 7′ Extra track / Sweeps，Guide Kit |
|
